规格型号Model Number

BD20C

驱动方式Drive Style

电动

转向方式Steering Type

电子转向

额定载重Rated Capacity

kg

2000

载荷中心Load Center

mm

700

轮距Wheel Base

mm

1450

整机重量Overall Weight

kg

930

轮子Wheel

聚胺酯轮

货叉最大高度Max Fork Height

mm

100

货叉最低高度Min Fork Height

mm

170

整机长度Overall Length

mm

2300

整机宽度Overall Width

mm

1200

货叉外宽Outer Fork Width

mm

1200

转弯半径Turning Radius

mm

2020

最大行驶速度（满载）Maximum travel speed (full load)

Km/h

6/6

最大行驶速度（空载）Maximum travel speed (Without load)

Km/h

6

下降速度(满载/空载) Maximum Falling Speed (full load /without load)

m/s

0.05/0.045

爬坡度(满载/空载) Grade (full load / without load)

%

5/8

行车制动Service Brake

电磁-再生制动

驱动电机Driving Motor

kW

1.5

提升电机Lifting Motor

kW

2

蓄电池Battery

V/Ah

24/240

蓄电池重量Battery Weight

Kg

260
