产品编号Model Number

GD0810R

GD1012R

安全工作载荷Rated Capacity

680Kg

1000Kg

延伸平台安全载荷Extended platform safety load

230kg

最大工作人数Maximum # of Persons

6

6-7

最大工作高度Max.Platform Work

10.00m

12.00m

最大平台高度Max.Platform Height

8.00m

10.00m

整机长度Overall Length

4.88m

整机宽度Overall Width

2.27m

整机高度Overall Height

2.65m

2.98m

工作平台尺寸Platform Size

3.98×1.83m

平台延伸尺寸Extended platform Size

1.43m×1.55m

最小离地间隙Minimum ground clearance

1.3×1.83m

轴距Wheel Base

2.86m

最小转弯半径(内轮/外轮)  Minimum turn radius(Inner Wheel/outer wheel)

2.35m/5.20m

发动机Engine

Perkins 404D22 38kw/3000rpm

机器行使速度（收拢状态）Running speed(folding)

6.8km/h

机器行使速度（起升状态）Running speed(rising)

1.1km/h

上升/下降速度Rising/falling speed

41/48s

 40/37 s

最大爬坡能力Maximum climbing ability

50%

50%

工作最大允许角度Maximum climbing ability

3°

液压油箱Hydraulic tank

130L

柴油箱Diesel tank

100L

轮胎Tire

33*12-20

整机重量Total Weight

3710kg

7940
